Name: Mosaic™ - Socket outlet - German std - 2P+E with cover - 2 mod - antimicrobial
SKU: 077219

Mosaic™ - Socket outlet - German std - 2P+E with cover - 2 mod - antimicrobial

Mosaic™ LEGRAND

Mosaic™ - Socket outlet - German std - 2P+E with cover - 2 mod - antimicrobial

REF. 077219 EAN. 3245060772192

Compare You can only compare 4 products, you must remove 1 to add this one

Mosaic™ Programme mechanisms - multi-support single and multiple sockets : German standard
Multi-support single sockets - German standard - For installation In =lush-mounting box, surface - mounting box, floor box, column module, desktop multi-outlet extension, office module and trunking 2P+E with cover - White antimicrobial - automatic terminals
White antimicrobial. Contains a silver compound to prevent the growth of bacteria on the surface.

Model	Socket outlet CEE 7/3 (type F)
Protective contact	Other
Number of active contacts (round)	1
Number of active contacts (flat)	0
With complemantary luminous signal	No
Number of ports USB-A	0
Number of ports USB-C	0
Number of units	1
Number of modules (module system)	2
Number of socket outlets switchable	0
Number of phases	1
Imprint/indication	None
Connection type	Push-in clamp
With hinged lid	Yes
With enhanced contact protection	Yes
Label space/information surface	No
Colour	White
RAL-number (similar)	9003
Metallic colour	No
Transparent	No
Lockable	No
Eject-mechanism	No
Insulated mounting	No
With function lighting	No
With orientation lighting	No
Over voltage protection	No
Fault current protection	No
With miniature fuse	No
Special power supply	No special power supply
Mounting method	Module frame
Type of fastening	Snap mounting (engagement)
Material	Plastic
Material quality	Thermoplastic
Halogen free	Yes

Surface protection	Untreated
Surface finishing	Glossy
Antimicrobial treatment	Yes
With loop through function	Yes
With on/off switch	No
Colour of switch operator	White
Rotated central insert	No
Nominal current	16 A
Nominal voltage	250 V
Frequency	50-60 Hz
Suitable for degree of protection (IP)	IP41
Degree of impact strength (IK)	IK04
Device width	45 mm
Device height	45 mm
Device depth	43 mm
Min. depth of built-in installation box	40 mm
Compatible with Apple HomeKit	No
Compatible with Amazon Alexa	No
Compatible with Google Assistant	No
IFTTT support available	No
With Wi-Fi signal repeater	No
With built-in bluetooth speaker	No
For heavy conditions according to VDE	No
Built-in depth	34.5 mm
Operating / setting temperature	-5-35 °C
Storage temperature	-10-70 °C
Voltage type	AC
Power Delivery	No
Cable nature for connection	Rigid
Cable section	2.5-2.5 mm²
Cable support	Other
Assembly arrangement	Basic element with central cover plate
Connected object	No
