Safety transformer 230 V / 12 V - 630 VA - 4 + 16 mm²

LEGRAND

Safety transformer 230 V / 12 V - 630 VA - 4 + 16 mm²

REF. 042765 EAN. 3245060427658
Download product sheet
You can only compare 4 products, you must remove 1 to add this one
Product charateristics
  • Transformers and auto-transformers IP 55 - class II - single-phase
  • Safety transformers - Conform to standard IEC EN 61558 - 2 - 6 - For 63 VA transformers : - Fuse cartridges : 5 x 20 time - delayed - Fuse carrier : Cat.No 0 371 81 - For 100 VA and greater transformers : - Up to 25 A : gG 10 x 38 fuse cartridges and fuse carrier Cat. No. 0 058 08 - From 25 A to 50 A : gG 14 x 51 fuse cartridges and fuse carrier Cat.No 0 215 01 - From 50 A upwards : gG 22 x 58 fuse cartridges and fuse carrier Cat.No 0 216 01 - C curve MCBsInput voltage = 230 V~ Output voltage = 12 V~ - Power : 630 VA - Primary terminal flexible cable : 4 mm² - Secondary terminal flexible cable cross - section : 16 mm²

Technical characteristics

Built as safety transformer Yes
Built as isolating transformer No
Built as energy saving transformer No
Primary voltage 1 230-230 V
Secondary voltage 1 12-12 V
Rated apparent power 630 VA
Type of insulation material according to IEC 85 B
Short-circuit-proof No
Relative short circuit voltage 3.7 %
Width 290 mm
Height 150 mm
Depth 190 mm
Degree of protection (IP) IP55
Ring core No
Suitable for mounting on PCB No
Modular version No

Documentation

1 document
Technical Guide
4 documents
Catalogue Technical Page
ex223001_0500.pdf pdf (0.05 Mo)
Catalogue Technical Page
ex223001_0504.pdf pdf (0.04 Mo)
Catalogue Technical Page
ex223001_0502-0503.pdf pdf (0.06 Mo)
Catalogue Commercial Page
ex223001_0496.pdf pdf (0.06 Mo)
1 document
3D Autocad
042725.dwg dwg (0.1 Mo)
